STARTING SYSTEM [SKYACTIV-X 2.0]
Warning:
– A hot engine can cause severe burns. Turn off the engine and wait until it is cool before removing the starter.
– If starter terminal B contacts the vehicle body with the battery terminal connected, it may cause a fire or damage to the electrical components. Always disconnect the negative battery terminal when removing the starter.
| Mazda CX-30 2019-2024 |
| 1. Starting system location index. [Skyactiv X 2.0]. |
| 2. Starter removal/installation. [Skyactiv X 2.0]. |
| 3. Starter inspection. [Skyactiv X 2.0]. |
| 4. Starter interlock switch inspection. [Skyactiv X 2.0]. |
1. Disconnect the negative battery terminal.
2. Open the engine cover.
3. Remove the left wall (rear) and left wall (front).
